Mini concrete mixer, or called portable concrete mixer is widely used in municipal projects, small water conservancy projects, housing construction and decoration, electric power communications projects.
This series concrete mixer is designed reasonable, compact structure, easy to operate and work stably, and it also has many advantages such as good mixing quality, high productivity, low energy consumption, low noise, with long life wearing parts.
Different Types:
We have samll concrete mixer & big ones to choose.
- RM Series:
| Model | RM-120 | RM-200 | RM-350 |
| Drum Capacity | 120L | 200L | 350L |
| Motor Power | 2.5KW | 2.5KW | 2.8KW |
| N.W/G.W (KG) | 46-51 | 62-65 | 90-95 |
| Stir Quantity (KG) | 40 | 110 | 300 |
| Thickness (MM) | 2 | 2 | 2.5 |
| Width (MM) | 610 | 700 | 790 |
| Distance to ground (MM) | 480 | 530 | 520 |
| Cartons Size (MM) | 730*580*400 | 790*750*490 | 940*780*820 |
| Motor Speed (RPM) |
1380-1400 |
||
Details:
- RMS Series
| Model | RMS-350 | RMS-400 | |
| Drum Capacity | 350L | 400L | |
| Discharge Capacity | 280L | 320L | |
| Productivity (M3/H) | 4-5 | 5-6 | |
| Roller Speed (RPM) |
25-30 |
||
| Thickness (MM) |
3 |
||
| Mixing Drum Size (MM) | 800×900 | 850×900 | |
| Power Option | Air-cooled Diesel Engine 178FS(6HP)
Air-cooled Diesel Engine186FS(10HP) Water-cooled Diesel EngineR175(6HP) Water- cooled Diesel EngineR180(8HP) Honda Gasoline EngineGX270(9HP) Electric Motor 3KW |
||
| Total Weight (KG) |
280 |
||
| Overall Size (L x W x H) |
1960x1100x1700MM |
2100x1200x1800MM |
|
- RMAF Series
| Model | RMAF-500 |
| Drum Capacity | 500L |
| Mixing Capacity | 400L |
| Productivity (M3/H) | 8-10 |
| Roller Speed (RPM) | 22 |
| Motor Power | 186FSE (10 HP) |
| Motor Engine | Air-cooled Diesel Engine |
| Drum Thickness | 2.75-3.75mm |
| Hopper Tipping | Hydraulic |
| Transmission Way | Chain |
| Type of The Tires | 4*(5.00-15) |
| Overall Dimension (L x W x H) | 2100*1300*2100mm |
| Weight (KG) | 1100 |
Details:
- RMWF Series
| Model | RMWF-510 |
| Drum Capacity | 510L |
| Mixing Capacity | 350L |
| Productivity (M3/H) | 20 |
| Roller Speed (RPM) | 30 |
| Motor Power | ZS1100(16HP) |
| Motor Engine | Water-cooled Diesel Engine |
| Drum Thickness | 2.75-3.75mm |
| Hopper Tipping | By Wire Rope |
| Transmission Way | Chain |
| Type of The Tires | 205/75/R14 |
| Overall Dimension (L x W x H) | 2300*1350*2750 mm |
| Weight (KG) | 1500 |
Details:
- ICMT Series
| Model | ICMT 3.0R | ICMT 3.5R | ICMT 4.0R |
| Engine Type |
Diesel Engine |
||
| Alternator |
28V–1500Wa (53.5A) |
||
| Battery |
2×12V–100AH (453A) |
2×12V–100AH (454A) |
|
| Steering |
2 steering wheels, Assisted by means of load-sensing power steering on 2 steering wheels |
Articulated Steering by two cylinders move alternately. Electro-hydraulically controlled mechanical gearbox for “working speed” and “road transfer speed” |
|
| 4×4 Four-wheel Drive |
hydraulic torque converter transmission with open Gear oil pump and reverse gear control on the steering wheel.
|
||
| Drum Volume | 5050L | 5550L | 6100L |
| Roller Speed(RPM) |
16 |
15 |
|
| Maximum Flow Rate |
63 L/min |
56L/min |
|
| Maximum Pressure |
35MPa |
||
| Loader Capacity |
550L |
800L |
|
| Fuel Tank |
200L |
135L |
|
| Hydraulic System Capacity |
200L |
240L |
|
| Engine Oil |
16L |
||
| Operating Weight | 7500kg | 7800kg |
8800kg |
| Max Gross Weight | 14700kg | 16200kg |
18400kg |
| Load-carrying Capacity | 7500kg | 8400kg |
9600kg |
Factory:
Package & Shipping:
