BASIC INFO
The 3 ton diesel forklift is a powerful and reliable solution for all your heavy-duty material handling needs. Designed with a robust diesel engine and durable structure, this forklift provides excellent performance in warehouses, factories, ports, construction sites, and logistics yards.
Specifications:
| Power type: | diesel |
| Rated lifting capacity: | 3000kg |
| Load center distance: | 500mm |
| Working mode: | seat type |
| Tire: | pneumatic tire |
| Lifting height: | 3000mm |
| Free lifting height: | 135mm |
| Fork specifications: | 1220*122*45mm |
| Gantry inclination: | 6/12 (front/rear) |
| Length (without fork): | 2750mm |
| Width: | 1255mm |
| Gantry non-lifting height: | 2000mm |
| Gantry lifting height: | 4000mm |
| Overhead guard height: | 2150mm |
| Turning radius: | 2515mm |
| Front overhang Distance/rear overhang: | 480mm |
| Minimum right-angle channel width: | 2230mm |
| Wheelbase: | 1760mm |
| Track: | front 1000mm |
| Track: | rear 970mm |
| Minimum ground clearance: | 130mm at mast |
| Minimum ground clearance: | axle center 200mm |
| Full-load operating speed: | 18km/h |
| No-load operating speed: | 19.5km/h |
| Full-load lifting speed: | 450mm/s |
| No-load lifting speed: | 500mm/s |
| Full-load lowering speed: | 450mm/s |
| No-load lowering speed: | 500mm/s |
| Maximum traction: | full load/no load 1696/1190kg |
| Maximum climbing grade: | full load/no load 15/18% |
| Engine: | Xinchai C490BPG |
| Rated power speed: | 40/2650kw/rpm |
| Maximum torque/speed: | 157/1800N.m/rpm |
| Number of cylinders: | 4 |
| Fuel consumption rate: | 228g/kw.h |
| Fuel tank capacity: | 60L |
